The Tohmei (formerly Mitsubishi Heavy Industries) Anti-Rolling Gyro (ARG) stabilisers significantly reduce boat roll at anchor and trolling speeds. Gyro technology originally developed for space vehicles is utilised to create forces opposing vessel roll (view theory of operation). The ARG can be fitted to virtually any commercial or pleasure craft to enhance passenger comfort and reduce crew fatigue.
- No protrusions on the hull for drag free operation.
- Very low maintenance.
- Robust and reliable design
- Simple installation - no water cooling, flat bed mounting, doesn't need to be on centerline.
- Can be installed on existing boats and new builds.
- Multiple units can be installed to generate greater anti rolling torque to further reduce roll.
- Typical Applications: Motor yachts and launches, coast guard vessels, ferries, diving boats, sightseeing vessels, sport fishing boats, pilot boats, research vessels etc.
| Model | Anti-Rolling Torque Nm (Max) |
Rated RPM | Weight kg |
Dimensions (W x L x H) |
Vessel Displacement Tons (Depends on Gm) |
|---|---|---|---|---|---|
| ARG50T DC | 5000 | 3200 | 236 | 750 x 520 x 525 | 10 |
| ARG 65T | 6500 | 4200 | 236 | 750 x 520 x 525 | 10 |
| ARG 175T | 17,500 | 4,600 | 380 | 950 x 620 x 630 | 25 |
| ARG 250T | 25,000 | 3,750 | 700 | 1020 x 720 x 700 | 40 |
| ARG250T-1 | 25000 | 3750 | 700 | 1080 x 720 x 700 | 40 |
| ARG 375T | 37,500 | 3,250 | 910 | 1120 x 830 x 780 | 60 |
ARG 50T
The ARG 50T Anti Rolling Gyro significantly reduces boat roll in vessels up to 10 ton displacement. The unit runs on 12VDC battery power.
ARG 65T
The ARG 65T Anti Rolling Gyro significantly reduces boat roll in vessels up to 10 ton displacement.
ARG 175T
The ARG 175T Anti Rolling Gyro significantly reduces boat roll in vessels up to 25 ton displacement
ARG 250T
The ARG 250T Anti Rolling Gyro significantly reduces boat roll in vessels up to 40 ton displacement
ARG 250T-1
The ARG 250T-1 Anti Rolling Gyro significantly reduces boat roll in vessels up to 40 ton displacement Using non linear damper technology roll reduction at smaller wave heights is significantly improved over the standard 250T model.
ARG 375T
The ARG 375T Anti Rolling Gyro significantly reduces boat roll in vessels up to 60 ton displacement
